Database - Drawing - Coding

EGYSCEMA Provides

Engineering certified and qualified to do P&ID,  Isometric Drawing, and Line Coding

•P&ID -has many standards that define the different symbols, which allow designing a P&ID diagram.

​

Standard P&ID should have the following:

​

​

Mechanical equipment with names and numbers

All valves and their identifications

Process piping, sizes

vents, drains, special fittings, and reducers

Permanent start-up and flush lines

Flow directions

Control inputs and outputs

Computer control system input

Identification of components and subsystems delivered by others

The intended physical sequence of the equipment

Equipment rating or capacity
